AEB Robotics WRL 200 also called the Mario Robot is a Cartesian robot with three interpolated axes and work area of 200x200mm; it is easy to program, highly flexible, made in Italy and economic.
The self-bearing structure made entirely of aluminium, the axes with toothed belts and ball bearing guides and the simple layout ensure a blend of high precision, ruggedness and stability with minimal weights and footprints.
The proprietor programming software is the ideal solution for dispensing applications, thanks to 3D interpolation with CONTINUOUS PATH function, to the new SUB-PROGRAMS function and to the automatic calibration system, making the programming work of operators of the even the most complex of paths very simple.
The robot is programmed from the PC via a remarkably user-friendly graphic interface and is subsequently controlled via the integrated operator panel ALPHA CP, being able to manage up to 100.000 points split-up into 255 processing programs.
The front panel also has START, PURGE and EMERGENCY buttons for operators to use; there are 2 digital inputs and 4 digital outputs to connect external devices (e.g. dispenser valves, level sensors, general enabling signals etc.), which are totally configurable by the user.
WRL200 is also available in the version WRL200CE with safety guards and EC type-approvals.
Technical Data
- Axes Motion System: 3-axis Cartesian system, bearing guides on hardened shafts
- Operating Range: X 200 mm, Y 200 mm, Z 100 mm
- Programming: Remote mode (self-learning) through PC software, Profiles imported from DXF, Excel and Gerber files
- Interpolation: Linear and 3D circular on X,Y,Z Point-to-point and Continuous path
- Control: ALPHA CP RS232 CanOpen® I/O
- Available I/O: 2 digital input 4 digital output
- PTP Speed: 1-300 mm/sec X, Y; 1-100 mm/sec Z
- Transportable Load Tool: 3 kg
- Repeatability: ±0,1 mm
- Dimensions: 480 x 584 x 797mm
- Weight: 23 kg
