DCT INJET 388 CRD

EN AT DE HU SI HR


DCT INJET 388 CRD

DCT INJET 388 CRD

DCT INJET 388 CRD
Send enquiry for this product!
INJET cleaning machines are using high pressure spray-in-air technology for cleaning and rinsing process. They are built as one- or multichamber devices, due to requested application and needed cleaning capacity. This technology is very effective for wide range of parts to clean as a stencils, misprinted PCBs, squeegees, pumprints, soldered PCBs and also maintenance parts cleaning applications. Available as a vertical or horizontal spraying device, with large portfolio of options which can be add due to customer request, needed capacity or level of final cleanness.

Number of chambers:

Processes: cleaning / rinsing / drying
Device dimensions: 1050 x 1325 1850 mm
Max. dimension of cleaned part: 190 x 860 x 790 mm
Weight (without cleaning fluids): 350 kg
Internal mechanical filtration: cleaning: 20 - 100 µm, rinsing: 5 - 20 µm
Flow rate | pressure of cleaning fluid: 125l/min / 2 Bar
Cleaning fluid consumption (per 1 cycle): 0,05 - 0,3l

To be forwarded to the cleaning fluids

Send enquiry for this product!

DCT INJET 388 CRD
